LCD DISPLAY 16*2 JHD
Non-returnable
LCD Module 16*4 has various different models on shelf and accept custom develop to meet your special requirement. We can develop different interface like I2C, Serial, and we also have different font available. Character 16x4 LCD Module is a dot matrix liquid crystal display module specially used for displaying letters, numbers, symbols, etc. It can display 4 lines with 16 characters in each line. Divided into 4-bit and 8-bit data transmission methods, it provides display data buffer DDRAM, character generator CGROM and character generator CGRAM.
₹0.00
Choose Quantity
Product Details
16X4 (S) COB yellow green Backlight Features:-
- LCD Type: STN- Positive Transflective
- Duty: 1/16 and Bias 1/5
- Viewing Angle: 6 O'clock
- Operating Temperature: -20 to + 70C
- Storage Temp: -30 to +80c
- Driver IC: ST7066U
- Drive Power: Vdd: 5V
16X4 (S) COB yellow green Backlight Specifications:-
- Display Format:- 16 × 4
- Model No:- SDCB1604-05
- Outline Dimension(mm):- 70.60 × 76.00 × 9.00
- Viewing Area(mm):- 60.00 × 31.40
- Color available:- Blue, Yellow-green, Grey
- IC:- AIP31066 or Eqv.
- IC Package:- COB
- Interface:- Parallel
