74HC4066
Non-returnable
The SN74HC4066 device is a silicon-gate CMOS quadruple analog switch designed to handle both analog and digital signals. Each switch permits signals with amplitudes of up to 6V (peak) to be transmitted in either direction. Each switch section has its own enable input control (C). A high-level voltage applied to C turns on the associated switch section. Applications include signal gating, chopping, modulation or demodulation (modem), and signal multiplexing for analog-to-digital and digital-to-analog conversion systems
₹30.00
Choose Quantity
Product Details
The 74HC4066 is a quadruple bilateral analog switch with several notable features:
- Wide Operating Voltage Range: 1V to 6V
- Low Power Consumption: Maximum ICC of 20μA
- Low Input Current: Maximum of 1μA
- High Linearity: Ensures accurate signal transmission
- Low On-State Impedance: Typically 50Ω at VCC = 6V
- Fast Switching: Typical enable time of 18ns
- High On-Off Output-Voltage Ratio: Ensures clear signal separation
- Low Crosstalk: Minimizes interference between switches
- Individual Switch Controls: Each switch has its own enable input control
