L7924
Non-returnable
he L7900AC series of three-terminal negative regulators is available in TO-220 and D2 PAK
packages and several fixed output voltages. These regulators can provide local on-card
regulation, eliminating the distribution problems associated with single point regulation;
furthermore, having the same voltage option as the L7800A positive standard series, they are
particularly suited for split power supplies. In addition, the -5.2V is also available for ECL
system. If adequate heat sinking is provided, they can deliver over 1.5A output current.
Although designed primarily as fixed voltage regulators, these devices can be used with external
components to obtain adjustable voltages and currents
₹30.00
Choose Quantity
Product Details
- OUTPUT CURRENT UP TO 1.5 A
- OUTPUT VOLTAGES OF -5; -5.2; -6; -8; -12;-15; -18; -20; -22; -24V
- THERMAL OVERLOAD PROTECTION
- SHORT CIRCUIT PROTECTION
- OUTPUT TRANSITION SOA PROTECTION
