HEX D FLIP-FLOP
The LSTTL / MSI SN54/ 74LS174 is a high speed Hex D Flip-Flop. The device is used primarily as a 6-bit edge-triggered storage register . The information on the D inputs is transferred to storage during the LOW to HIGH clock transition. The device has a Master Reset to simultaneously clear all flip-flops.
The LS174 is fabricated with the Schottky barrier diode process for high speed and is completely compatible with all Motorola TTL families
•Edge-Triggered D-Type Inputs
•Buffered-Positive Edge-Triggered Clock
•Asynchronous Common Reset
•Input Clamp Diodes Limit High Speed Termination Effects
